ES-FF730G

EPIC ES-FF730Gr

ES-FF730G
5way

UNLOCK METHODS

BASIC FUNCTION

Pin Number 1
RFID Card (external) 200
RFID Card (internal)
Fingerprint (external) 100
Fingerprint (internal)
Guest Pin Number 1
Remote Control 10
Face ID -
Emergency Key (mechanical)
Home Network 10
App Possible
(Need to BLE)
BLE Built-in
(new)
WiFi Bridge Option
(new)
Smart Card Auto-Recognition / Manual Recognition
Deadbolt Auto Lock / Manual lock
Sound Setting (UP/DOWN)
Door Open Alarm ON/OFF
Voice Mode/Buzzer Mode Setting
Internal Forced Lock ON/OFF
External Forced Lock Setting
Alarm Notification ON/OFF
Dual Authentication ON/OFF
IR SENSOR ON/OFF -
FeliCa Auto-Detection ON/OFF
Etiquette Mode

OTHER FUNCTION

SPECIFICATIONS

Low Battery Warning
1 Minute Lock Warning
Deadbolt Operation Error Warning
Intrusion Alarm
High Temperatur Alarm
Internal Forced is being enabled
External Forced is being enabled
Random Number Feature
Checking The Duration Of Use
Automatic Lock/Re-lock
Locking from Outside/Inside
Emergency Power DC 9V
Outer body (W x H x D mm) 74 x 180 x 26
Inner body (W x H x D mm) 75 x 187 x 55
Material Zn, ABS
Applicable Door Thickness(mm) 40 ~ 50mm
Backset(mm) 40mm
Operation Humidity 10% ~ 90%
Operation Temperature -20℃ ~ 55℃
Fire Detection Temperature 60℃ ± 10℃
Power Supply DC 6V
(LR6 1.5V AA, 4 EA)
Emergency Battery DC 9V
Battery life (10 times/1 day) 10 months
