UNLOCK METHODS

BASIC FUNCTION

Pin Number 1
RFID Card (external) -
RFID Card (internal) -
Fingerprint (external) 100
Fingerprint (internal) -
Guest Pin Number 1
Remote Control 10
Face ID 30
Emergency Key (mechanical) -
Home Network 10
App(BLE/WiFi Bridge) Possible
(Need to BLE)
Smart Card Auto Recognition / Manual Recognition -
Deadbolt Auto Lock / Manual lock
Sound Setting (UP/DOWN)
Door Opening Alarm ON/OFF
Voice Mode/Buzzer Mode Setting
Internal Forced Lock ON/OFF
External Forced Lock ON/OFF
Alarm Notification ON/OFF
Dual Authentication ON/OFF
IR SENSOR ON/OFF
FeliCa Auto Detection ON/OFF -
Etiquette Mode

OTHER FUNCTION

SPECIFICATIONS

Low Battery Warning
1 Minute Lock Warning
Deadbolt Operation Error Warning
Intrusion Alarm
High Temperatur Alarm
Internal Forced is being enabled
External Forced is being enabled
Random Number Feature
Checking The Duration Of Use
Automatic Lock/Re-lock
Locking from Outside/Inside
Emergency Power Terminal
Outer body (W x H x D mm) 70 x 176 x 20
Inner body (W x H x D mm) 75 x 187 x 48
Material Zn, ABS
Applicable Door Thickness(mm) 40 ~ 50mm
Operation Humidity 20% ~ 80% RH
Operation Temperature 0℃ ~ 50℃
Fire Detection Temperature 60℃ ± 10℃
Power Supply DC 6V
(LR6 1.5V AA, 8 EA)
Emergency Power USB C-type 5V
Battery life (10 times/1 day) 7 months
Liveness detection TAR: 98% @ FAR: 1:100000
Face comparison TAR: 98% @ FAR: 1:1000000
