UNLOCK METHODS
BASIC FUNCTION
Pin Number | 1 |
---|---|
RFID Card (external) | - |
RFID Card (internal) | - |
Fingerprint (external) | 100 |
Fingerprint (internal) | ✓ |
Guest Pin Number | 1 |
Remote Control | 10 |
Face ID | 30 |
Emergency Key (mechanical) | ✓ |
Home Network | 10 |
App(BLE/WiFi Bridge) | Possible (Need to BLE) |
Smart Card Auto Recognition / Manual Recognition | - |
---|---|
Deadbolt Auto Lock / Manual lock | ✓ |
Sound Setting (UP/DOWN) | ✓ |
Door Opening Alarm ON/OFF | ✓ |
Voice Mode/Buzzer Mode Setting | ✓ |
Internal Forced Lock ON/OFF | ✓ |
External Forced Lock ON/OFF | ✓ |
Alarm Notification ON/OFF | ✓ |
Dual Authentication ON/OFF | ✓ |
IR SENSOR ON/OFF | ✓ |
FeliCa Auto Detection ON/OFF | - |
Etiquette Mode | ✓ |
OTHER FUNCTION
SPECIFICATIONS
Low Battery Warning | ✓ |
---|---|
1 Minute Lock Warning | ✓ |
Deadbolt Operation Error Warning | ✓ |
Intrusion Alarm | ✓ |
High Temperatur Alarm | ✓ |
Internal Forced is being enabled | - |
External Forced is being enabled | ✓ |
Random Number Feature | ✓ |
Checking The Duration Of Use | ✓ |
Automatic Lock/Re-lock | ✓ |
Locking from Outside/Inside | ✓ |
Emergency Power Terminal | ✓ |
Outer body (W x H x D mm) | 70 x 176 x 20 |
---|---|
Inner body (W x H x D mm) | 75 x 187 x 48 |
Material | Zn, ABS |
Applicable Door Thickness(mm) | 40 ~ 50mm |
Operation Humidity | 20% ~ 80% RH |
Operation Temperature | 0℃ ~ 50℃ |
Fire Detection Temperature | 60℃ ± 10℃ |
Power Supply | DC 6V (LR6 1.5V AA, 8 EA) |
Emergency Power | USB C-type 5V |
Battery life (10 times/1 day) | 7 months |
Liveness detection | TAR: 98% @ FAR: 1:100000 |
Face comparison | TAR: 98% @ FAR: 1:1000000 |
